Focal length | 150mm～1500mm continuous zoom |
Detector | 640×512 cooled MCT |
Wavelengh | 3.7μm-4.8μm |
Pixel Pitch | 15μm |
NETD | ≤25mk@25℃ |
Cooling time | ≤8 minutes at room temperature |
Analog video output standard | PAL system analog video signal |
Digital video output | Cameralink/SDI |
Frame rate | 50Hz |
Control electrical interface | RS422 |
Correction | Manual correction, background correction |
polarity | White hot/black hot switching |
Digital zoom | ×2 、×4 Digital zoom |
weight | ≤36kg |
size | 770mm(L)×316mmW×365mm(H) |
Operating Voltage | Dc 24-32V, power supply with input polarity protection |
Power consumption | ≤15W@25℃, standard working state power consumption |
FOV | 0.36°(H)×0.29°(V)-3.6°×2.9° ±10% |
Operating temperature | -40℃~+55℃ |
storage temperature | -40~+70℃ |
