Focal length | 15mmÿ300mm continuous zoom |
Detector | 640×512 RefrigerationMCT |
Wavelengh | 3.7μm-4.8μm |
Pixel spacing | 15μm |
NETD | ≤25mk@25℃ |
Cooling time | ≤8 minutes at room temperature |
Analog video output standard | PAL system analog video signal |
Digital video output | Cameralink/SDI |
Frame rate | 50Hz |
Control electrical interface | RS232/RS422 |
Correction | Manual correction, background correction |
polarity | White hot/black hot switching |
electronic amplification | ×2, ×4 electronic amplification |
weight | ≤2.2kg |
size | 241mm(l)×110mmW×96mm(H) |
Operating Voltage | DC 24-32V, power supply with input polarity protection |
Power consumption | ≤15W@25℃, standard working state power consumption |
field of view | 18.3(H)×14.7°±10% |
Operating temperature | -40℃~+60℃ |
storage temperature | -40~+70℃ |
