Focal length | 4 0 mm ~ 200 mm continuous zoom |
Detector | 640×512 RefrigerationMCT |
Wavelengh | 3.7μm-4.8μm |
Pixel spacing | 15μm |
NETD | ≤25mk@25℃ |
Cooling time | ≤8 minutes at room temperature |
Analog video output standard | PAL system analog video signal |
Digital video output | Cameralink/SDI |
Frame rate | 50Hz |
Control electrical interface | RS422 |
Correction | Manual correction, background correction |
polarity | White hot/black hot switching |
electronic amplification | ×2, ×4 electronic amplification |
weight | ≤1.1kg |
size | 199mm(U×98mmW×66mm(H) |
Operating Voltage | DC 18-32V, power supply with input polarity protection ≤15W@25℃, |
Power consumption | standard working state power consumption |
Digital video output | Cameralink/SDI |
Operating temperature | -40℃~+60℃ |
storage temperature | -40~+70℃ |
