| Resolution -Frame Rate-Recording Time | ||||
| SKU | LEITH-HSC1300-13600E | LEITH-HSC1300-9300E | LEITH-HSC1300-6800E | LEITH-HSC4900-2000E |
| Sensor type | CMOS | CMOS | CMOS | CMOS |
| Resolution | 1280×1024 | 1280x 1024 | 1280x 1024 | 2560x 1920 |
| ISO | 67000(M),23000(C) | 67000(M),23000(C) | 67000(M),23000(C) | 22000(M),7000(C) |
| Shutter | Global shutter | Global shutter | Global shutter | Global shutter |
| Min. exposure time | 100ns | 100ns | 100ns | 100ns |
| PIV cross-frame | 400ns | 400ns | 400ns | 400ns |
| Exposure | Auto exposure | Auto exposure | Auto exposure | Auto exposure |
| Ultimate dynamic range | Support | Support | Support | Support |
| Resolution-Frame Rate-Recording Time | ||||||||
| Resolution | LEITH-HSC1300-13600E (measured at 256GB) | LEITH-HSC1300-930OE (measured at 256GB) | LEITH-HSC1300-6800E (measured at 256GB) | LEITH-HSC4900-2000E (measured at 256GB) | ||||
| Max Frame Rate fps | Recording time-s | Max Frame Rate fps | Recording time-s | Max Frame Rate fps | Recording time-s | Max Frame Rate fps | Recording time-s | |
| 2560×1920 | -- | -- | -- | -- | -- | -- | 2,057 | 27.1 |
| 1920×1080 | -- | -- | -- | -- | -- | -- | 3,649 | 36.2 |
| 1280×1024 | 13,600 | 16.4 | 9,300 | 23.8 | 6,800 | 32.7 | 3,846 | 54.3 |
| 1280×960 | 14,200 | 16.4 | 9,900 | 23.8 | 7,100 | 32.8 | 4,098 | 54.4 |
| 1280×800 | 17,200 | 16.4 | 11,900 | 23.8 | 8.600 | 32.6 | 4,926 | 54.3 |
| 1280×720 | 18,800 | 16.4 | 13,100 | 23.9 | 9,500 | 32.6 | 5,464 | 54.4 |
| 832×600 | 22,700 | 25.4 | 15,800 | 36.4 | 11,000 | 23.2 | 6,535 | 83.7 |
| 640×600 | 22,700 | 32.6 | 15,800 | 47.4 | 11,300 | 65.3 | 6,535 | 108.9 |
| 640×480 | 22,700 | 30.0 | 19,600 | 47.8 | 14,000 | 59.4 | 8,130 | 109.4 |
| 512×256 | 50,000 | 43.0 | 37,000 | 60.0 | 25,600 | 83.9 | 15,151 | 137.5 |
| 256×256 | 50,000 | 85.9 | 37,000 | 120.0 | 25,600 | 167.7 | 15,151 | 274.7 |
| 512×128 | 100,000 | 44.4 | 100,000 | 44.4 | 52,600 | 84.4 | 29,411 | 141.5 |
| 128x128 | 100,000 | 176.5 | 100,000 | 176.7 | 52,600 | 335.7 | -- | -- |
| 512×8 | 1,000,000 | 64.7 | 1,000,000 | 64.8 | 500,000 | 129.5 | 250,000 | 258.8 |
| 128×8 | 1,000,000 | 237.3 | 1,000,000 | 237.6 | 500,000 | 475.1 | -- | -- |
| Memory | ||||
| Model | LEITH-HSC1300-13600E | LEITH-HSC1300-9300E | LEITH-HSC1300-6800E | LEITH-HSC4900-2000E |
| RAM high-speed storage | 64G, 256G | 64G, 256G | 64G, 256G | 64G, 256G |
| Power | ||||
| Model | LEITH-HSC1300-13600E | LEITH-HSC1300-9300E | LEITH-HSC1300-6800E | LEITH-HSC4900-2000E |
| ACpower supply | 100-240VAC 8owpower adapter included | 100-240VAC 8owpower adapter included | 100-240VAC 8owpower adapter included | 100-24OVAC 8owpoweradapter included |
| Voltage range | 9~16V | 9~16V | 9~16V | 9~16V |
| Power consumption | ≤45W | ≤45W | ≤45W | ≤45W |
| Mechanical Specifications | ||||
| Model | LEITH-HSC1300-13600E | LEITH-HSC1300-9300E | LEITH-HSC1300-6800E | LEITH-HSC4900-2000E |
| Lens interface | E | E | E | E |
| Size W*HxD/mm | 170x185 x304 (with handle) | 170x185 x304 (with handle) | 170x185 x304 (with handle) | 170x185 x304 (with handle) |
| Weight (without accessories)/g | ≤6350 | <6350 | ≤6350 | ≤6350 |
| *Mounting holes | Emount: bottom 1/4 in. 2 pcs.M5 threaded holes 4 pcs, 3/8 in.2pcs | Emount: bottom 1/4 in. 2 pcs.M5 threaded holes 4 pcs. 3/8 in.2pcs | Emount: bottom 1/4 in. 2 pcs.M5 threaded holes 4 pcs, 3/8 in.2pcs | Emount: bottom 1/4 in. 2 pcs.M5 threaded holes 4 pcs, 3/8 in.2pcs |
| Cooling | Fan cooling | Fan cooling | Fan cooling | Fan cooling |
