| Product Number | LEITH-SP15-20 |
| Multispectral Imaging | 7+RGB |
| Multispectral Bands | (Standard configuration)450nm, 550nm, 650nm, 720nm (narrowband),750nm(narrowband),800nm,850nm (optional)410nm, 49Onm, 530nm,570nm,600nm, 660nm, 680nm, 720nm, 750nm, 780nm,900nm |
| lmage Sensor | 1/2.9 inch CMOs, global shutter, 1.55 million pixels |
| lmage Resolution | 1440*1080 |
| Data Depth | 12bit |
| Optical Lens | Focal length f=5.35mm, aperture F/2.0 |
| Field of view | HFOV:49.8°,VFOV:38.4° |
| Acquisition frame rate | 20 frames/second (real time) |
| Spectral lmage Format | IMG(ENVl standard),TIFF/JPG |
| Storage Capacity | MicroSD, standard capacity 128G |
| Device Interface | 1x RJ-45 Gigabit Ethenet port, 1x USB3.0,1x Mini-HDMl,1x RS 232,2x 1/O port |
| Device Extension | Support GPS/IMU, WIFl, downlink light sensor through interface expansion |
| Software Support | Dedicated spectrum acquisition control software, providing SDK for secondary development |
| Dimensions (WxHxD) | Gimbal camera: 129x145x177mm, downlink light sensor:75x47x31mm |
| Shooting Method | Shooting method: real-time collection |
| Power Supply | DC 12V/2A |
| Power Consumption | <10w |
| Weight | 766g |
| Size | 123mm*115mm*79mm |
| Operating Temperature | -20°C to 50°C |
