| Model No. | Magnific ation (X) | Working Distance (mm) | Object View (mm) | Image Field (mm) | Resolution (μm) | Aperture (f/#) | NA | Telecent ricity | Field Of View (mm) | Optical Distortion | MTF30（lp/ mm） | Depth Of Field (mm) | O/I | Mount | Whether Coaxial | Dimension (mm) | Weight (kg) | ||
| (°) | （H×V） | ||||||||||||||||||
| LEITH- ST02X110- 230 | 0.2 | 110 | / | / | 23.25 | F7.8 | 0.012 | <0.1 | 2/3” | <0.05% | / | 8.775 | / | C | NO | φ70×13 4.92 | 344 | ||
| LEITH- ST02X110- 230C | 0.2 | 110 | / | / | 23.25 | F7.8 | 0.012 | <0.1 | 2/3” | <0.05% | / | 8.775 | / | C | YES | φ70×13 8.21 | 360 | ||
| LEITH- ST03X110- 120 | 0.3 | 110 | 26.7 | 8 | 33 | F15 | 0.01 | 0.03 | 1/2" | 21 | 16 | 0.31% | 65 | 18.1 | 261.5 | C | NO | φ43*13 4 | / |
| 1/3" | 3 | 12 | |||||||||||||||||
| 16 | |||||||||||||||||||
| LEITH- ST03X110- 120C | 0.3 | 110 | 26.7 | 8 | 33 | F15 | 0.01 | 0.03 | 1/2" | 21 | 16 | 0.80% | 65 | 18.1 | 264.6 | C | YES | φ43*13 7.1 | / |
| 1/3" | 3 | 12 | |||||||||||||||||
| 16 | |||||||||||||||||||
| LEITH- ST03X110- 230 | 0.3 | 110 | / | / | 15.5 | F7.9 | 0.019 | <0.1 | 2/3” | <0.05% | / | 3.95 | / | C | NO | φ70×14 6.27 | 356 | ||
| LEITH- ST03X110- 230C | 0.3 | 110 | / | / | 15.5 | F7.9 | 0.019 | <0.1 | 2/3” | <0.05% | / | 3.95 | / | C | YES | φ70×14 9.56 | 372 | ||
| LEITH- ST05X110- 120 | 0.5 | 110 | 16 | 8 | 22 | F16.6 | 0.015 | 0.12 | 1/2" | 12 | 9.6 | 0.17% | 60 | 7 | 233.8 | C | NO | φ29*10 6.3 | / |
| 1/3" | 8 | 7.2 | |||||||||||||||||
| 9.6 | |||||||||||||||||||
| LEITH- ST05X110- 110C | 0.5 | 110 | / | / | 10.5 | F8 | / | ＜0.06 | 1/2" | 6.4 | 4.8 | ＜0.162% | 25 | 3.5 | / | C | YES | φ50×11 2.6 | / |
| LEITH- ST05X110- 120C | 0.5 | 110 | 16 | 8 | 22 | F16.7 | 0.015 | 0.17 | 1/2" | 12 | 9.6 | 0.14% | 60 | 7.1 | 237.1 | C | YES | φ29* 109.6 | / |
| 1/3" | 8 | 7.2 | |||||||||||||||||
| 9.6 | |||||||||||||||||||
| LEITH- ST05X110- 110C | 0.5 | 110 | / | / | 10.5 | F8 | / | ＜0.06 | 1.1" | 14.2 | 10.4 | ＜0.162% | 25 | 3.5 | / | C | YES | φ50× 112.6 | / |
| 2/3" | 8.45 | 7.07 | |||||||||||||||||
| 1/2" | 6.4 | 4.8 | |||||||||||||||||
| LEITH- ST05X110- 230 | 0.5 | 110 | / | / | 12 | F9.3 | 0.027 | <0.1 | 2/3” | <0.05% | / | 1.674 | / | C | NO | φ35× 120.5 | 113 | ||
| LEITH- ST05X110- 230C | 0.5 | 110 | / | / | 12 | F9.3 | 0.027 | <0.1 | 2/3” | <0.05% | / | 1.674 | / | C | YES | φ35× 123.83 | 129 | ||
| LEITH- ST08X110- 120 | 0.8 | 110 | 10 | 8 | 16.5 | F20 | 0.02 | 0.53 | 1/2" | 8 | 6 | 0.08% | 50 | 3.4 | 232.5 | C | NO | φ16* 105 | / |
| 1/3" | 6 | 4.5 | |||||||||||||||||
| LEITH- ST08X110- 120C | 0.8 | 110 | 10 | 8 | 16.5 | F20 | 0.02 | 0.73 | 1/2" | 8 | 6 | 0.06% | 50 | 3.3 | 235 | C | YES | φ16* 107.5 | / |
| 1/3" | 6 | 4.5 | |||||||||||||||||
| LEITH- ST08X110- 230 | 0.8 | 110 | 13.8 | 11 | 13.8 | F16.7 | 0.024 | 0.08 | 2/3" | 10.6 | 8.8 | 0.01% | 60 | 2.9 | 244.7 | C | NO | φ30* 117.2 | / |
| 1/2" | 8 | 6 | |||||||||||||||||
| 1/3" | 6 | 4.5 | |||||||||||||||||
| LEITH- ST08X110- 230C | 0.8 | 110 | 13.8 | 11 | 13.8 | F16.7 | 0.024 | 0.08 | 2/3" | 10.6 | 8.8 | 0.01% | 60 | 2.9 | 247.6 | C | YES | φ30* 120.1 | / |
| 1/2" | 8 | 6 | |||||||||||||||||
| 1/3" | 6 | 4.5 | |||||||||||||||||
| LEITH- ST08X110A- 230C | 0.8 | 110 | / | / | 6.25 | F8.9 | 0.045 | <0.15 | 2/3” | <0.05% | / | 0.55 | / | C | YES | / | / | ||
| LEITH- ST08X110A- 230 | 0.8 | 110 | / | / | 6.25 | F8.9 | 0.045 | <0.15 | 2/3” | <0.05% | / | 0.55 | / | C | NO | / | / | ||
| LEITH- ST10X110- 110C | 1 | 110 | / | / | 6.5 | F10 | / | ＜0.08 | 1.1" | 14.2 | 10.4 | ＜0.08% | 100 | 1.10% | / | C | YES | φ50×1 51.5 | / |
| 2/3" | 8.45 | 7.07 | |||||||||||||||||
| 1/2" | 6.4 | 4.8 | |||||||||||||||||
| LEITH- ST10X110- 230 | 1 | 110 | 8 | 8 | 13.8 | F20.8 | 0.024 | 0.6 | 2/3" | 6.4 | 4.8 | 0.06% | 50 | 2.3 | 229.8 | C | NO | φ16*1 02.3 | / |
| 1/2" | 4.8 | 3.6 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH- ST10X110- 230C | 1 | 110 | 8 | 8 | 13.8 | F20.8 | 0.024 | 0.6 | 2/3" | 6.4 | 4.8 | 0.05% | 50 | 2.3 | 233.1 | C | YES | φ16*1 05.6 | / |
| 1/2" | 4.8 | 3.6 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH- ST10X110A- 230 | 1 | 110 | 11 | 11 | 13.8 | F20.8 | 0.024 | 0.07 | 2/3" | 8.45 | 7.07 | 0.03% | 50 | 2.3 | 254.3 | C | NO | φ30*1 26.7 | / |
| 1/2" | 6.4 | 4.8 | |||||||||||||||||
| 1/3" | 4.8 | 3.6 | |||||||||||||||||
| LEITH- ST10X110A- 230C | 1 | 110 | 11 | 11 | 13.8 | F20.8 | 0.024 | 0.07 | 2/3" | 8.45 | 7.07 | 0.03% | 50 | 2.3 | 257 | C | YES | φ30*1 29.5 | / |
| 1/2" | 6.4 | 4.8 | |||||||||||||||||
| 1/3" | 4.8 | 3.6 | |||||||||||||||||
| LEITH- ST10X110B- 230 | 1 | 110 | / | / | 7.4 | F11 | 0.045 | <0.1 | 2/3” | / | / | 0.495 | / | C | NO | φ30×1 28.451 | 106 | ||
| LEITH- ST10X110B- 230C | 1 | 110 | / | / | 7.4 | F11 | 0.045 | <0.1 | 2/3” | / | / | 0.495 | / | C | YES | φ30× 130.43 | 122 | ||
| LEITH- ST20X110-230 | 2 | 110 | 4 | 8 | 7.3 | F22.1 | 0.045 | 0.16 | 2/3" | 3.2 | 2.4 | 0.30% | 40 | 0.52 | 209.5 | C | NO | φ20* 82 | / |
| 1/2" | 2.4 | 1.8 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH- ST20X110-230C | 2 | 110 | 4 | 8 | 7.3 | F22.2 | 0.045 | 0.16 | 2/3" | 3.2 | 2.4 | 0.30% | 40 | 0.5 | 212.8 | C | YES | φ20* 85.3 | / |
| 1/2" | 2.4 | 1.8 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH- ST20X110A-230 | 2 | 110 | / | / | 4.5 | F13.6 | 0.074 | <0.1 | 2/3” | <0.05% | / | 0.153 | / | C | NO | φ30× 130.48 | 128 | ||
| LEITH- ST20X110A- 230C | 2 | 110 | / | / | 4.5 | F13.6 | 0.074 | <0.1 | 2/3” | <0.05% | / | 0.153 | / | C | YES | φ30× 133.02 | 143 | ||
| LEITH- ST30X110-230 | 3 | 110 | 2.7 | 8 | 6 | F27.1 | 0.055 | 0.11 | 2/3" | 2.13 | 1.6 | 0.13% | 30 | 0.24 | 235.1 | C | NO | φ20* 107.6 | / |
| 1/2" | 1.6 | 1.2 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH- ST30X110-230C | 3 | 110 | 2.7 | 8 | 6 | F27.2 | 0.055 | 0.11 | 2/3" | 2.13 | 1.6 | 0.13% | 30 | 0.25 | 237.8 | C | YES | φ20* 110.3 | / |
| 1/2" | 1.6 | 1.2 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH- ST30X110A-230 | 3 | 110 | / | / | 3.5 | F17.6 | 0.085 | <0.1 | 2/3” | <0.1% | / | 0.088 | / | C | NO | / | / | ||
| LEITH- ST30X110A- 230C | 3 | 110 | / | / | 3.5 | F17.6 | 0.085 | <0.1 | 2/3” | <0.1% | / | 0.088 | / | C | YES | / | / | ||
| LEITH-ST40X110- 230 | 4 | 110 | 2 | 8 | 7.3 | F44.3 | 0.045 | 0.08 | 2/3" | 1.6 | 1.2 | 0.33% | 22 | 0.23 | 216.4 | C | NO | φ16*8 8.9 | / |
| 1/2" | 1.2 | 0.9 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH-ST40X110- 230C | 4 | 110 | 2 | 8 | 7.3 | F44.1 | 0.045 | 0.001 | 2/3" | 1.6 | 1.2 | 0.30% | 22 | 0.22 | 219.6 | C | YES | φ16*9 2.1 | / |
| 1/2" | 1.2 | 0.9 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH- ST40X110A-230 | 4 | 110 | / | / | 3.7 | F22 | 0.09 | <0.1 | <0.05% | / | 0.061875 | / | C | NO | φ30×1 10.24 | 99 | |||
| LEITH- ST40X110A-230C | 4 | 110 | / | / | 3.7 | F22 | 0.09 | <0.1 | 2/3” | <0.05% | / | 0.061875 | / | C | YES | φ30×1 13.47 | 117 | ||
| LEITH-ST60X110- 230 | 6 | 110 | 1.3 | 8 | 7.3 | F66.1 | 0.045 | 0.05 | 2/3" | 1.07 | 0.8 | 0.07% | 15 | 0.15 | 233.1 | C | NO | φ16*1 05.6 | / |
| 1/2" | 0.8 | 0.6 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH-ST60X110- 230C | 6 | 110 | 1.3 | 8 | 7.3 | F66.1 | 0.045 | 0.001 | 2/3" | 1.07 | 0.8 | 0.06% | 15 | 0.13 | 236.7 | C | YES | φ16*1 09.2 | / |
| 1/2" | 0.8 | 0.6 | |||||||||||||||||
| 1/3" | |||||||||||||||||||
| LEITH- ST60X110A-230 | 6 | 110 | / | / | 4 | F35 | 0.085 | <0.1 | 2/3” | <0.02% | / | 0.04375 | / | C | NO | φ30×1 57.22 | 149 | ||
| LEITH- ST60X110A-230C | 6 | 110 | / | / | 4 | F35 | 0.085 | <0.1 | 2/3” | <0.02% | / | 0.04375 | / | C | YES | φ30×1 61.85 | 166 | ||
