| Focal length | 25-225mm |
| F/# | 1.5 |
| Spectral Range | 8-12μm |
| Detector resolution and pixel | 640×512(17μm)、336×256(17μm) |
| FOV | 24.4°×20°~2.7°×2.2° 13 ° ×10°~1.4°×1.1° |
| Transmittance | ≥80%(DLC) |
| Focus Mode | Electromotion Focus |
| Drive Voltage | DC12V |
| Weight | ≤5.5kg |
| Optical Machine Size | φ198×L265 |
| Operating Temperature | -40℃~+60℃ |
| Storage Temperature | -45℃~+70℃ |
| First piece protection class | IP67 |
| Support RS422/RS485 transparent communication with thermal camera | |
| Supports autofocus and external trigger focus | |
| Support online modification of lens magnification and focusing temperature calibration coefficient | |
| Equipped with lens calibration software | |
