Focal length | 23mm~450mm continuous zoom |
Detector | 640×512 RefrigerationMCT |
Wavelengh | 3.7μm-4.8μm |
Pixel spacing | 15μm |
NETD | ≤25mk@25℃ |
Cooling time | ≤8 minutes at room temperature |
Analog video output standard | PAL system analog video signal |
Digital video output | Cameralink/SDI |
Frame rate | 50Hz |
Control electrical interface | RS232 |
Correction | Manual correction, background correction |
polarity | White hot/black hot switching |
electronic amplification | ×2, ×4 electronic amplification |
weight | ≤3.2kg |
size | 302mmU×137mmW)×137mmH) |
Operating Voltage | DC 18-32V, power supply with input polarity protection |
Power consumption | ≤15W@25℃, standard working state power consumption |
field of view | 1.22°(H)×0.98°(V) to 23.91°(H)×19.13(V)±10% |
Operating temperature | -30℃~+60℃ |
storage temperature | -40~+70℃ |
