| Shooting speed and exposure time | |
| Sensor Type | CMOS |
| Maximum Resolution | 1920x1080 |
| Pixel Size | 10μm |
| ISO | 25000(M),8000(C) |
| Electronic Shutter | Global |
| Minimum exposure time | 100ns |
| PIV Across Frames | 400ns |
| Exposure Function | Automatic Exposure |
| Extreme Dynamic Range | Support |
| Resolution -Frame Rate-Recording Time | ||||||
| Resolution | LEITH-HSC200-3003E(measured at 1TB) | LEITH-HSC200-2000E(measured at 64GB) | LEITH-HSC131-2000E(measured at 16GB) | |||
| Max Frame Rate fps | Recording(s) | Max Frame Rate fps | Recording(s) | Max Frame Rate fps | Recording(s) | |
| 1920×1080 | 3,003 | 173.7 | 2,000 | 15.5 | -- | -- |
| 16472×900 | 3,597 | 226.9 | 2,389 | 20.2 | -- | -- |
| 1280×1024 | 3,164 | 260.7 | 2,109 | 23.2 | 2,000 | 6.5 |
| 1280×960 | 3,378 | 260.4 | 2,252 | 23.2 | 2,132 | 6.5 |
| 1280×800 | 4,048 | 260.8 | 2,702 | 23.2 | 2,557 | 6.5 |
| 1280×768 | 4,219 | 260.6 | 2,808 | 23.2 | 2,666 | 6.5 |
| 1280×720 | 4.504 | 260.3 | 3,003 | 23.2 | 2,840 | 6.5 |
| 832×600 | 5,405 | 400 | 3,597 | 35.7 | 2,412 | 10.0 |
| 640×480 | 6,756 | 519.6 | 4,504 | 46.3 | 4,273 | 13.0 |
| 640×256 | 12,658 | 518.6 | 8,403 | 46.4 | 8.000 | 13.0 |
| 256×128 | 25,000 | 1,281.10 | 16,949 | 112.4 | 15,873 | 32.0 |
| 256×16 | -- | -- | -- | -- | 125,000 | 26.8 |
| 128×16 | 125,000 | 1691.1 | -- | -- | -- | -- |
| Resolution -Frame Rate -Recording Time | |||
| lnterface | Description | Definition | Remarks |
| PWR/LAN | Power and lnterface | 1-8 pin: Connect cable 9 pin: GND 10-15 pin: Internal debugging is not open to the public 16, 17 pin: Negative pole of power supply 18,19 pin: Positive pole of power supply | 1. Power interface, from which the camera is powered; 2.Gigabit network interface, datatransmission betweencamera and PC |
| l/O | lnput, Output | 1,5,7,11,13,17 pin:GND 2,3,4,6 pin:PlV 8pin:TRIG, 9 pin reserve 10,12 pin:SYNC_IN SYNC_oUT 14 pin:lRIG_B 15, 16:RS422 TX_P, TX_N 18, 19 pin:RS422RX_P,RX_N | 1.Trigger interface,5O2 BNC; 2.Synchronous input interface,TTL level interface; 3. Synchronous output interface,TTL level interface; 4.B code interface, DC code, 50QBNC,TTL level; 5.RS422 interface.Communication lnterface. Support protocol customization, such as PTZ, lens, etc.; 6.PiV interface, 4 single-ended BNC,TTL level. |
| SDl | SDl Interface | Power and lnterface | |
| lndicator light | PWR | 1. lt is always on after the external power supply is connected; 2. It detects that the internal temperature of the device is toohigh and enters the flashing state control (5Hz); 3.The device enters breathing state control in standby mode. | |
| OL | 1.The online mode control light is always on; 2.Offline mode control light is flashing (5Hz); 3. ln the offline mode, if it fails to enter the high-speedacquisition, it is always off; 4. In offline mode, the status of data recovery or external triggeracquisition is blinking(1Hz). | ||
| SMP | Highlight flashing, export and export preview breathing lights. | ||
| DISP | Blinks when there is data transmission in the network, and isalways off at other times | ||
| INIT | 1.The breathing state indicates that it is being initialized; 2.The constant light status indicates that the initialization iscomplete; 3.Blinking status indicates initialization failure(5Hz) | ||
