Focal length | 35mmÿ700mm continuous zoom |
Detector | 640×512 RefrigerationMCT |
Wavelengh | 3.7μm-4.8μm |
Pixel spacing | 15μm |
NETD | ≤25mk@25℃ |
Cooling time | ≤8 minutes at room temperature |
Analog video output standard | PAL system analog video signal |
Digital video output | Cameralink/SDI |
Frame rate | 50Hz |
Control electrical interface | RS232 |
Correction | Manual correction, background correction |
polarity | White hot/black hot switching |
electronic amplification | ×2, ×4 electronic amplification |
weight | ≤9.5kg |
size | 403mm(L)×206mm(W×206mmH) |
Operating Voltage | DC 18-32V, power supply with input polarity protection |
Power consumption | ≤15W@25℃, standard working state power consumption |
field of view | 0.78°(H)×0.63°(V) to 15.6°(H)×12.5°(V)±10% |
Operating temperature | -30℃~+55℃ |
storage temperature | -40~+70℃ |
