| Model No. | Magnific ation (X) | Working Distance (mm) | Object View (mm) | Image Field (mm) | Resolution (μm) | Aperture (f/#) | NA | Telecent ricity | Field Of View (mm) | Optical Distortion | MTF30（lp/ mm） | Depth Of Field (mm) | O/I | Mount | Whether Coaxial | Dimension (mm) | ||
| (°) | （H×V） | |||||||||||||||||
| LEITH-HT018X150-230 | 0.18 | 150 | / | / | 48 | F12.6 | 0.00714 | ≤ 0.1 | 2/3" | 46.89 | 39.28 | ≤ 0.1% | / | 30 | / | C | NO | φ30x77.2 |
| 1/1.8" | 40.94 | 27.33 | ||||||||||||||||
| 1/2" | 34.11 | 27.33 | ||||||||||||||||
| LEITH-HT0188X167-230 | 0.188 | 167 | / | / | 10.6 | F6.8 ~ F40 | 0.01382 | ≤ 0.1 | 2/3" | 44.89 | 37.61 | ≤ 0.1% | / | 8.4 | / | C | NO | φ76x227.3 |
| 1/1.8" | 39.2 | 26.17 | ||||||||||||||||
| 1/2" | 32.66 | 26.17 | ||||||||||||||||
| LEITH-HT027X120-230 | 0.27 | 120 | / | / | 37.3 | F14.3 | 0.00944 | ≤ 0.1 | 2/3" | 31.26 | 26.19 | ≤ 0.9% | / | 1.25 | / | C | NO | φ28x43.7 |
| 1/1.8" | 27.3 | 18.22 | ||||||||||||||||
| 1/2" | 22.74 | 18.22 | ||||||||||||||||
| LEITH-HT045X135-230C | 0.45 | 135 | / | / | 23 | F15.8 | 0.01424 | ≤ 0.1 | 2/3" | 18.76 | 15.71 | ≤ 0.1% | / | 6.4 | / | C | YES | φ34x123.8 |
| 1/1.8" | 16.38 | 10.93 | ||||||||||||||||
| 1/2" | 13.64 | 10.93 | ||||||||||||||||
| LEITH-HT05X225-125 | 0.5 | 225 | / | / | 12.1 | F9 | 0.02778 | ≤ 0.1 | 1/2.5" | 11.4 | 8.6 | ≤ 0.1% | / | 2.9 | / | C | NO | φ30x163.8 |
| 1/3" | 9.6 | 7.2 | ||||||||||||||||
| 1/4" | 6.4 | 4.8 | ||||||||||||||||
| LEITH-HT07X145-230 | 0.7 | 145 | / | / | 14.3 | F11.2 | 0.03125 | ≤ 0.1 | 2/3" | 12.06 | 10.1 | ≤ 0.1% | / | 3.2 | / | C | NO | φ28x110.4 |
| 1/1.8" | 7.03 | 10.53 | ||||||||||||||||
| 1/2" | 8.77 | 7.03 | ||||||||||||||||
| LEITH-HT08X130-120 | 0.8 | 130 | / | / | 19.7 | F23.5 | 0.01702 | ≤ 0.1 | 1/2" | 7.68 | 6.2 | ≤ 1% | / | 2.9 | / | C | NO | φ8x97.1 |
| 1/3" | 6 | 4.5 | ||||||||||||||||
| 1/4" | 4 | 3 | ||||||||||||||||
| LEITH-HT018X150-230 | 0.18 | 150 | / | / | 48 | F12.6 | 0.00714 | ≤ 0.1 | 2/3" | 46.89 | 39.28 | ≤ 0.1% | / | 30 | / | C | NO | φ30x77.2 |
| LEITH-HT08X130-120C | 0.8 | 130 | / | / | 19.7 | F23.5 | 0.01702 | ≤ 0.1 | 1/2" | 7.68 | 6.2 | ≤ 1% | / | 2.9 | / | C | YES | φ28x110.5 |
| 1/3" | 6 | 4.5 | ||||||||||||||||
| 1/4" | 4 | 3 | ||||||||||||||||
| LEITH-HT08X130-230 | 0.8 | 130 | / | / | 9.4 | F11.2 | 0.03571 | ≤ 0.1 | 2/3" | 10.55 | 8.84 | ≤ 0.1% | / | 1.4 | / | C | NO | φ8x97.1 |
| 1/1.8" | 9.21 | 6.15 | ||||||||||||||||
| 1/2" | 7.68 | 6.15 | ||||||||||||||||
| LEITH-HT08X130-230C | 0.8 | 130 | / | / | 9.4 | F11.2 | 0.03571 | ≤ 0.1 | 2/3" | 10.55 | 8.84 | ≤ 0.1% | / | 1.4 | / | C | YES | φ28x121.4 |
| 1/1.8" | 9.21 | 6.15 | ||||||||||||||||
| 1/2" | 7.68 | 6.15 | ||||||||||||||||
| LEITH-HT08X150-120C | 0.8 | 150 | / | / | 22.7 | F27 | 0.01481 | ≤ 0.1 | 1/2" | 7.68 | 6.15 | ≤ 0.1% | / | 3.3 | / | C | YES | φ16x80.2 |
| 1/3" | 6 | 4.5 | ||||||||||||||||
| 1/4" | 4 | 3 | ||||||||||||||||
| LEITH-HT08X250-230C | 0.8 | 250 | / | / | 16.8 | F20 | 0.02 | ≤ 0.1 | 2/3" | 10.55 | 8.84 | ≤ 0.2% | / | 2.2 | / | C | YES | φ28x230.9 |
| 1/1.8" | 9.21 | 6.15 | ||||||||||||||||
| 1/2" | 7.68 | 6.15 | ||||||||||||||||
| LEITH-HT10X178-110 | 1 | 178 | 17.6 | 17.6 | 7.3 | F11.1 | 0.045 | <0.13 | 1.1" | 14.2 | 10.4 | <0.066% | ＞0.3@90 | 1.2 | 366.5 | C | NO | φ42x171 |
| 2/3" | 8.5 | 7.1 | ||||||||||||||||
| 1/2" | 6.4 | 4.8 | ||||||||||||||||
| LEITH-HT10X178-110C | 1 | 178 | 17.6 | 17.6 | 7.3 | F11.1 | 0.045 | <0.13 | 1.1" | 14.2 | 10.4 | <0.066% | ＞0.3@90 | 1.2 | 366.5 | C | YES | φ42x171 |
| 2/3" | 8.5 | 7.1 | ||||||||||||||||
| 1/2" | 6.4 | 4.8 | ||||||||||||||||
| LEITH-HT10X180-120C | 1 | 180 | / | / | 8.9 | F13 | 0.03846 | ≤ 0.1 | 1/2" | 6.14 | 4.92 | ≤ 1.4% | / | 1 | / | C | YES | φ28x104.2 |
| 1/3" | 4.8 | 3.6 | ||||||||||||||||
| 1/4" | 3.2 | 2.4 | ||||||||||||||||
| LEITH-HT10X180-120 | 1.5 | 250 | / | / | 13.4 | F29.7 | 0.02525 | ≤ 0.1 | 1/2" | 4.09 | 3.28 | ≤ 0.1% | / | 1 | / | C | NO | φ16x141.5 |
| 1/3" | 3.2 | 2.4 | ||||||||||||||||
| 1/4" | 2.13 | 1.6 | ||||||||||||||||
